PART NUMBER: 61-3255
Developed with and made by CSF, this is Goodwin Racing's new all-aluminum ultra efficient performance radiator for the Fiat 124, a bit over 20 percent more capacity than stock and all aluminum.For max overheating protection match this all aluminum radiator upgrade with our all aluminum Fiat 124 expansion tank and HIGHER pressure cap, which raises the boiling point of the entire cooling system.
- Advanced fin and tube technology:
Utilizes CSF's specially-engineered "B-tubes" which are made from thinner and lighter aluminum but are still stronger than conventional 0-shape tubes. The core features louvered fins with a denser packing. More fins per inch than standard cores means more surface area for cooling and thus dramatically higher efficiency.
- 31mm core for peak efficiency and light weight:
Conventional high-performance radiators with low fin counts and standard tubes have no choice but to increase the core thickness to get more cooling. This core is roughly quarter inch thicker than stock and far less than two inch race cores used on some turbo Miata applications. The thicker core units slow down the air more, and that hurts efficiency, so you get diminishing returns as the core gets thicker and thicker. A thicker core also means a heavier radiator. The new generation of radiator advances used in this unit allow us to achieve a new "best" for cooling ability without any need to massively increase core size. This 31mm core allows for fast airflow, further improving performance, and keeps the weight well below classic 2 inch thick racing radiators. The relatively thin core, about a quarter inch more than stock, also means the unit can drop in place of the factory unit without the need for relocating anything.
~Military Grade (special clad) aluminum used for tubes, fins, fitments, and side brackets (JIS 3003 spec minumum)
~ "B-Tube" Technology - Most efficient tube in the world
~ High Efficiency Louvered Fin
~ OE radial and deep drawn aluminum endtanks
~ Wind tunnel tested for optimal radiator core cooling performance
~ Stronger joint design for mountings, fan shrouds and condensers
~ OE Specific Mounting
~ "Drop-in" fitment requiring no modifications
~ CNC Machined brackets and fittings
~ Racing Style all-aluminum drain plug
~ Brazed in CAB Furnace
~ ISO 9001/9002 certification
~ Privately owned factories with full "In house" toolrooms
~ "Master Class" TIG welding
~ Individually leak tested
~ Vibration cycle tested
~ Thermal cycle tested
~ Burst pressure cycle tested 10,000 times for strength
~ Salt spray tested for corrosion protection
~ 10 foot box "drop test" to ensure packaging protection
~ 30 minute, hand polished "Sho-Stopper mirror finish"
~ Application specific foam packaging
~ Industry leading, shock resistant 5-ply box
~ Over 45+ years in business
~ Over 500,000 radiators and condensers sold every year
~ Over 35 million radiators sold worldwide
~ Over 10 world's first exclusive applications
"B-Tube" technology - Unlike a regular oval shape "O" type radiator tube, CSF uses a specially engineered tube in a shape of a "B". These "B-tubes" are carefully formed and then brazed over the seam to seal. CSF is able to use thinner and lighter aluminum material (better cooling efficiency) because this design is actually stronger than normal "O" shape tubes that are welded.
The design (inlet in the middle of tube that is seam brazed) increases the heat transfer surface area of the tube by approximately 15% over regular tubes. You get the efficiency of 2 smaller tubes vs. 1 large tube within the same space criteria. With "B-tubes" you are able to get "dual liquid laminar flow."
The tubes are made from aircraft grade special clad aluminum and are intricately formed on our high precision 6-stage tubeforming mill. No other aftermarket radiator manufacturer uses this technology. This technology raises the bar and sets the standard for high performance radiator cores.
Automatic Transmission: This radiator fits BOTH manual and automatic cars. Includes formed hard lines for the automatic transmission lines to connect to. Radiator ships with caps on those lines. If you have a manual transmission, you can just leave those lines capped off and do not use them. We recommend you match this all aluminum radiator upgrade with our all aluminum expansion tank and HIGHER pressure cap, which raises the boiling point of the entire cooling system for max overheating protection.
INSTALL TIPS: YOU MUST vacuum fill and get all air bubbles out to get the benefit you are buying here. If you don't know what it means to vacuum fill the radiator just Google it and watch the videos. YES, raced in our Fiat 124 at SCCA events with upgraded turbo and 17x10 wheels.
INSTALL TIPS, must vacuum fill and get all air bubbles out to get the benefit you are buying here. YES, raced in our Fiat 124 at SCCA events with upgraded turbo and 17x10 wheels.
The packaging was excellent. Build quality looks great. If works as advertised, I'll just be a happy camper. Thank You
